- 2 SIP Profiles via 1 FXS Port and 1 FXO Port
- Dual 100Mbps LAN and WAN ports
- Lifeline support (FX Sport will be hard-relayed to FXO port) in case of power outage
- 3-way voice conferencing per port
- Automated & secureprovisioning optionsusing TR069
- Supports T.38 Fax for reliable Fax-over-IP
Datasheet:
Telephone Interfaces | One (1) RJ11 FXS port | One (1) RJ11 FXO PSTN line port with lifeline support |
---|---|
Network Interface | STROM | LAN | WAN | FXS | FXO |
Telephony Features | Caller ID display or block | call waiting | flash | blind or attended transfer | forward,hold | do not disturb | 3-way conference |
Voice Codecs | G.711 with Annex I (PLC) and Annex II (VAD/CNG) | G.723.1, G.729A/B | G.726 | iLBC | OPUS | dynamic jitter buffer | advanced line echo cancellatio |
Fax over IP | T.38 compliant Group 3 Fax Relay up to 14.4kpbs and auto-switch to G.711 for Fax Pass-throug |
Short/Long Haul Ring Load | 3 REN: Up to 1km on 24 AWG |
Caller ID | Bellcore Type 1 & 2 | ETSI | BT | NTT | DTMF-based CID |
Disconnect Methods | Busy Tone | Polarity Reversal/Wink, Loop Current |
Network Protocols | TCP/IP/UDP | RTP/RTCP | HTTP/HTTPS | ARP/RARP | ICMP | DNS | DHCP | NTP | TFTP | TELNET | STUN | SIP (RFC3261) | SIP over TCP/TLS | SRTP | TR-069 |
QoS | Layer 2 (802.1Q VLAN, SIP/RTP 802.1p) and Layer 3 (ToS, Diffserv, MPLS) |
DTMF Methode | In-audio | RFC2833 and/or SIP INFOO |
Provisioning and Control | HTTP | HTTPS | TFTP | SSH | TR-069 | cure and automated provisioning usiing AES | Syslog |
Safety | SRTP | TLS | SIPS | HTTPS |
Universal Power Supp | Input: 100-240VAC | 50-60Hz | Output: 12V/0.5 |
Environmental | In Betrieb: Operational: 32 – 104F or 0 – 40C | Storage: 14 – 140F or -10 – 60C | Humidity: 10 – 90% Non-condensing |
Dimension and Weigh | 130.5 x 90.5 x 29 mm (L x W x D) | Weight: 0.142Kg |
Art.No.: VOGRSTHT813
