- 1.27Gbps wireless throughput and 2x Gigabit wireline ports
- Dual-band 2×2:2MU-MIMO with beam-forming technology
- Support 802.3af and 802.3at Power-over-Ethernet (PoE/PoE+)
- Support 450+ concurrent WiFi client devices
- Up to 300-meter coverage range
- Advanced QoS to ensure real-time performanceof low-latency applications
- Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
- Embedded controller allows GWN7600LR to auto-discover, auto-provision and manage up to 30 GWN series WiFi APs in a network
Description GWN7600LR:
| WiFi Standards/Antennas | IEEE 802.11 a/b/g/n/ac (Wave-2) | 2×2.4 GHz, gain 4 dBi, internal antenna | 2×5 GHz, gain 5 dBi, internal antenna |
|---|---|
| WiFi Data Rates | IEEE 802.11ac: 6.5 Mbps to 867 Mbps | IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps | IEEE 802.11n: 6.5 Mbps to 300 Mbps; 400 Mbps with 256-QAM on 2.4GHz | IEEE 802.11b: 1, 2, 5.5, 11 Mbps | IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
| Channel Bandwidth/Frequenzbänder/MIMO | 2,4G: 20 and 40 MHz | 5G: 20, 40 and 80 MHz | 2,4G: 20 and 40 MHz 5G: 20, 40 and 80 MHz | 2×2:2 2,4GHz (MIMO), 2×2:2 5GHz (MU-MIMO) |
| Maximum TX Power/Receiver Sensitivity | 2,4G: 26dBm (FCC) / 16dBm (CE) | 5G: 26dBm (FCC) /18dBm (CE) | 2.4G 802.11b:-100dBm @1Mbps,-93dBm@11Mbps;802.11g:-95dBm @6Mbps,-76dBm@54Mbps; 802.11n 20MHz:-72dBm @MCS7;802.11n 40MHz:-70dBm @MCS7 | 5G 802.11a:-93dBm @6Mbps, -76dBm @54Mbps;802.11ac 20MHz:-68dBm @MCS8;802.11acHT40: -65dBm @MCS9;802.11ac 80MHz:-60dBm @MCS9 |
| SSIDs | 16 SSIDs per radio |
| Gleichzeitige angebandene End-geräte | 450+ |
| Network Interfaces | 2x autosensing 10/100/1000 Base-T Ethernet Ports | 1x Reset Pinhole |
| Mounting | Outdoor base bracket and cover bracket included |
| Network Protocols QoS | IPv4, 802.1Q, 802.1p, 802.1x, 802.11e/WMM |
| Power and Green Energy Efficiency | Power over Ethernet 802.3af and 802.3at compliant | Maximum Power Consumption: 12.9 W (PoE supply); 23.0 W (PoE+ supply |
| dimensions | Unit Dimension: 290×150×35mm; Unit Weight: 708g | Unit + Mounting Kits Dimension : 290×150×56mm; Unit + Mounting Kits Weight: 1528.2g | Entire Package Dimension: 423×187×97mm; Entire Package Weight: 1844g |
| Waterproof Grade | IP66-level weatherproof capability when installed vertically |
Outdoor Long Range 802.11ac Wave-2 WiFi Access Point
This long range WiFi access point is designed to provide extended coverage support and is ideal for outdoor WiFi solutions thanks to its waterproof casing and heat resistant technology. The GWN7600LR comes equipped with dual-band 2×2:2 MU-MIMO with beam-forming technology and a sophisticated antenna design for maximum network throughput and extended WiFi coverage range of up to 300 meters. To ensure easy installation and management, the GWN7600LR uses a controller-less distributed network management design and an embedded controller within the products web user interface. This allows each access point to manage a network of up to 30 GWN APs independently without needing separate controller hardware/software and without a single point-of-failure. Its easy installation and management features packed with extra coverage support and advanced performance features, make the GWN7600LR an ideal outdoor access point for mid-size wireless network deployments.
Art.No.: VOGRSTGWN7610LR
